Description
CASE TYPE
Mid Tower
Dimension (H x W x D)
505 x 200 x 493mm
(19.9 x 7.9 x 19.4 inch)
NET WEIGHT
6.7 kg / 14.9 lb
SIDE PANEL
Transparent Window
Color
Exterior & Interior : Black
MATERIAL
SPCC
COOLING SYSTEM
Rear (exhaust):
120 x 120 x 25 mm Riing RGB fan
(1400rpm, 28dBA) x 1
Drive Bays
-Accessible
-Hidden
-Accessible
-Hidden
2 x 3.5’’ or 2.5’’(with HDD tray)
4 x 2.5’’ (with the M/B tray)
EXPANSION SLOTS
8 + 2
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
I/O Port
USB 3.0 x 2,USB 2.0 x 1, HD Audio x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front:
3 x 120mm
Rear:
1 x 120mm
Power Cover:
1 x 120mm
RADIATOR SUPPORT
Front:
1 x 360mm
Rear:
1 x 120mm
CLEARANCE
CPU cooler height limitation:
155mm
VGA length limitation:
410mm (Without Front Fan)
?Suggested VGA thickness up to 40mm(2-slot reference card standard) with 7mm space for ventilation if extending for VGA card
PSU length limitation:
180mm
LED Controller Supports Up To 8 Thermaltake Riing RGB Fans(Hardware Edition)
