Description
Series
Core
CASE TYPE
Mid Tower
Dimension (H x W x D)
470 x 470 x 615 mm
(18.5 x 18.5 x 24.2 inch)
NET WEIGHT
17.2 kg / 37.9 lb
SIDE PANEL
5mm Tempered Glass x 2 (Left & Right)
Color
Black
MATERIAL
SPCC
COOLING SYSTEM
–
Drive Bays
-Accessible
-Hidden
3 x 2.5’’ (HDD Bracket) ; 2 x 3.5” or 2 x 2.5” (Optional)
2 x 3.5’’ or 2 x 2.5’’ (Behind the M/B tray)
EXPANSION SLOTS
8
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
LCS Upgradable
–
I/O Port
USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Right Side:
4 x 120mm
3 x 140mm
RADIATOR SUPPORT
Right Side:
1 x 480mm
1 x 420mm
CLEARANCE
CPU cooler height limitation: 180mm
VGA length limitation: 320mm
PSU length limitation: 220mm
