The Tower 100 Snow Mini Chassis

SKU: CA-1R3-00S6WN-00

The Tower 100 Snow is a vertically designed mini-ITX chassis with panoramic viewing. It comes with two preinstalled 120mm standard fans and three 4mm tempered glass windows at the front, on left and right side.

The Tower 100 Snow Mini Chassis
Designed to expand the legacy of The Tower 900 E-ATX Super Tower Chassis, The Tower 100 Snow Mini Chassis is the newest member of The Tower Series. It features three 4mm tempered glass windows for a stunning view and two preinstalled 120mm standard fans on top and at the rear for exhaust. It is a much smaller version of The Tower 900 with dimensions of 462.8mm (Height), 266mm (Width), 266mm (Depth).

Though it may not be the smallest Mini-ITX chassis on the market, it is a highly capable one that can fit high-end components like the RTX 30 Series Graphics Cards. The Tower 100 Snow Mini Chassis is designed to target users who have a limited space at their workplace or at home, or those who simply do not want their PC to take too much space. No matter if you are a regular users, gamers, or content creators, etc. you will find it ideal and can place it almost anywhere in your room.

The Tower 100 Snow is a vertically designed case constructed with solid steel all around, the vertical design allows the chassis to have a smaller footprint, and helps to minimize obstruction to your gaming and workspace area. The vertical design also helps extract heat from the chassis by using a chimney effect, intaking cold air from the base and dispelling the heat via the top.

Description

P/N CA-1R3-00S6WN-00
Series The Tower
Model The Tower 100 Snow
CASE TYPE Mini Tower
Dimension (H x W x D) 462.8 x 266 x 266 mm
(18.2 x 10.5 x 10.5 inch)
NET WEIGHT 6.1 kg / 13.45 lbs.
PANEL Tempered Glass x 3 (4mm thickness)
Color Black
MATERIAL SPCC
COOLING SYSTEM Top(exhaust):
120 x 120 x 25 mm Standard fan (1500rpm, 35.8 dBA) x 1
Rear(exhaust):
120 x 120 x 25 mm Standard fan (1500rpm, 35.8 dBA) x 1
Drive Bays
-Accessible
-Hidden

2 x 2.5“(with side bracket);
2 x 3.5” (without rear fan)
EXPANSION SLOTS 2
MOTHERBOARDS 6.7” x 6.7” (Mini ITX)
I/O Port USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 2
PSU Standard PS2 PSU (optional)
FAN SUPPORT Top:
1 x 120mm, 1 x 140mm
Rear:
1 x 120mm, 1 x 140mm
Top of the PSU Cover:
1 x 120mm, 1 x 140mm
RADIATOR SUPPORT Top:
1 x 120mm
CLEARANCE CPU cooler height limitation: 190mm
VGA length limitation: 330mm
PSU length limitation: 180mm
