EATON 9SX 1500I RACK 2U

SKU: 9SX1500IR
,

Eaton 9SX UPS, 1500 VA, 1350 W, Input: C14, Outputs: (6) C13, Rack, 2U

Brand:

Description

Product Name
Eaton 9SX UPS
Catalog Number
9SX1500IR
UPC
743172090966
Product Length/Depth
438 mm
Product Height
86.5 mm
Product Width
438 mm
Product Weight
18.4 kg
Compliances
CE Marked
TUV
cULus Listed
CSA 22.2
FCC part 15 Class B
CISPR22 Class B
Certifications
IEC/EN 62040-1
UL 1778
IEC/EN 62040-2
CE
cULus Listed
EAC

Additional information

Electrical output

Receptacle: (6) C13
Voltage: 230V
Wattage: 1350 W
Output power factor: 0.9
Output voltage range: 200/208/220/230/240 V +/- 2%
Output waveform: Sine wave
Output nominal voltage: 230V default (200/208/220/230/240V)
Voltage distortion output (linear load) – max: 3
Feed type: 1
Topology: Online/Double-conversion
VA rating: 1500 VA
Environmental

Altitude: 3000 m
Noise level: <43 dB at 1 meter
Temperature range: 0° to 40°C (32° to 104°F)
Relative humidity: 0-95% non-condensing
