Description

Specifications in detail
General Specifications
Machine Type
Colour Laser All-In-One
Available Functions
Print, Copy, Scan and Fax
Print Specifications
Print Speed

Single sided: Up to 25 ppm (A4)

Up to 45.3 ppm (A5-Landscape)
Double sided: Up to 15 ipm (A4)
Printing Method
Colour laser beam printing
Print Resolution
Up to 1200 x 1200 dpi
Warm-up Time
Approx. 13 seconds or less from power on
First-Print-Out Time
Colour approx.: 10.93 seconds or less
Mono approx.: 10.90 seconds or less
Printer Languages
UFRII, PCL 5c2, PCL6, Adobe® PostScript3
Fonts
93 PCL fonts
136 PostScript fonts
Print Margins
5 mm-top, bottom, left and right
10 mm-top, bottom, left and right (Envelope)
Toner Saver Mode
Yes
Advanced Printing Features
Encrypted Secure Print
Secure Print
Print from USB memory key (JPEG/TIFF/PDF)
Print from Cloud (Dropbox, GoogleDrive, OneDrive) (PDF/JPEG)
Microsoft Universal Print support
Barcode Print3
iOS: AirPrint, Canon PRINT app
Android; Mopria certified, Canon Print Service Plug-in, Canon PRINT app, IPP everywhere
Copy Specifications
Copy Speed
Single sided (A4): Up to 25 ppm
Double sided (A4): Up to 15 ipm
First-Copy-Out Time
ADF (A4):
Colour Approx. 10.6 seconds or less
Mono Approx. 10.5 seconds or less

Platen (A4):
Colour Approx. 11.2 seconds or less
Mono Approx. 11.0 seconds or less
Copy Resolution
Up to 600 x 600 dpi
Copy Modes
Text/Photo/Map (Default),Text/Photo/Map (quality), Printed Image, Text
Double Sided Copying
2-sided to 2-sided (Automatic)
Multiple Copies
Up to 999 copies
Reduction / Enlargement
25-400% in 1% increments
Other Features
Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Two-sided Original, Sort, N on 1, Sharpness, Erase Frame, Copy ID Card, Copy Passport, Color Mode, Reserved copy
Scan Specifications
Standard Type
Colour
Scan Resolution
Optical: Up to 600 x 600 dpi
Enhanced: Up to 9600 x 9600 dpi
Scan Speed
Single sided mono: 50ipm (300x300dpi)
Single sided colour: 40ipm (300x300dpi)
Double sided mono: 100ipm (300x300dpi)
Double sided colour: 80ipm (300x300dpi)
Single sided mono: 40ipm (300x600dpi)
Single sided colour: 20ipm (300x600dpi)
Double sided mono: 80ipm (300x600dpi)
Double sided colour: 40ipm (300x600dpi)
Colour Scanning Depth
24 bit/24 bit (input/output)
Greyscales
256 levels
Compatibility
TWAIN, WIA, ICA
Maximum Scan Width
216mm
Scan to E-mail
TIFF/JPEG/PDF/Compact PDF/Searchable PDF/Encrypted PDF1/PDF (Digital signature)2 / PDF/A-1b
Scan to PC
TIFF/JPEG/PDF/Compact PDF/Searchable PDF/Encrypted PDF3/PDF (Digital signature)4 / PDF/A-1b
Scan to USB Memory Key
TIFF/JPEG/PDF/Compact PDF/Searchable PDF/Encrypted PDF5/PDF (Digital signature)6 / PDF/A-1b
Scan to FTP
TIFF/JPEG/PDF/Compact PDF/Searchable PDF/Encrypted PDF7/PDF (Digital signature)8 / PDF/A-1b
Scan to Cloud
TIFF/JPEG/PDF/PNG9
iFAX
ITU-T.37
Fax Specifications
Modem Speed
33.6 Kbps (Up to 3 seconds/page10)
Receive Mode
Fax only, Fax/Tel Auto Switch, Answer Mode, Manual
Fax Resolution
Standard: 200 x 100 dpi
Fine: 200 x 200 dpi
Super fine: 200 x 400 dpi
Ultra fine: 400 x 400 dpi
Fax Memory
Up to 512 pages11
Speed Dials
Up to 281 dials
Group Dials/Destinations
Max. 299 dials / Max. 299 destinations
Sequential Broadcast
Max. 310 destinations
Memory Backup
Permanent fax memory backup (Backup with flash memory)
Double Sided Faxing
Yes (Transmit and Receive)
Media Handling
Scanner Type
Platen, 2-sided ADF (single pass)
Paper Input (Standard)
250-sheet cassette
1-sheet manual feed slot
50-sheet ADF
Maximum Paper Input Capacity
251 sheets
Paper Output
100-sheet
Media Types
Plain paper, Recycled paper, Heavy Paper, Thin paper, Colour paper, Coated paper, Label, Post card, Envelope
Media Sizes
Cassette:
A4, A5, A5 (Landscape), B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelop (COM10, DL, C5, Monarch), Custom sizes: Min. 76.2 x 127 mm, Max. 216 x 355.6 mm.

Multi-purpose tray:
A4, A5, A5 (Landscape), B5,A6, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelope (COM10, DL, C5, Monarch), Custom sizes: Min 76.2 x 127 mm, Max. 216 x 355.6 mm.

ADF:
A4, A5, A6, B5, Legal, Letter, Statement, Custom sizes: Min. 48 x 85.0 mm, Max. 216.0 x 355.6 mm
Media Weights
Cassette: 60 to 163 g/m² (Up to 200 g/m² with Coated paper)
Multi-purpose tray: 60 to 163 g/m² (Up to 200 g/m² with Coated paper)
ADF: 50 to 105 g/m²
Double Sided Printing
Automatic
Cassette:
A4, B5, Legal, Letter, Executive, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K
Custom size – Min. 182 x 257 mm, Max. 216.0 x 355.6 mm
60 to 200 g/m²
Interface & Software
Interface Type
USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T, Wireless 802.11b/g/n, Wireless Direct Connection
Operating System Compatibility
Windows® 11 / Windows® 10 / Server® 2025 /Server® 2022 / Server® 2019 / Server® 2016
Mac OS X version 10.15 & up
Linux12
Network Protocol
Print:
TCP/IP (LPD/Port9100/IPP/IPPS/WSD)
Scan:
Push Scan: File: FTP (TCP/IP), SMB3.1.1 (TCP/IP)
E-mail/I-Fax: SMTP (send), POP3 (receive)
Pull Scan: TCP/IP

Management:
SNMPv1, SNMPv3 (IPv4,IPv6)

Security:
TLS1.3, IPSec, IP address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
Security (wireless):
Infrastructure Mode:
WPA-PSK(AES), WPA2-PSK(AES), WPA3-SAE (AES), WPA-EAP(AES), WPA2-EAP(AES), WPA3-EAP(AES)
Access Point Mode:
WPA2-PSK(AES), WPA3-SAE (AES)
Software and Printer Management
MF Scan Utility,
Remote User Interface (RUI),
Department ID Management,
Toner Status Tool,
iW Enterprise Management Console: Server-based software for centralised management of a fleet of devices
Cooperating with External Security Audit System (Security Information and Event Management)
eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics.
Application Library
General Features
Recommended Monthly Print Volume
250 – 2,500 pages per month
Duty Cycle
Max. 30,000 pages per month13
Processor Speed
1200MHz
Memory
1GB
Storage
4GB
Control Panel
12.7 cm LCD Colour Touch Screen
Dimensions with Trays (W x D x H)
425 mm x 461 mm x 397 mm
Installation Space (W x D x H)
701 mm x 1,020 mm x 785 mm
Weight
Approx. 20.8 Kg
Operating Environment
Temperature: 10 to 30ºC (50 to 86ºF)
Humidity: 20 to 80% RH (no condensation)
Power Source
220-240V(±10%) 50/60Hz (±2Hz)
Power Consumption
Maximum: Approx. 980 W
Active printing: Approx. 580 W
Standby: Approx. 12.0 W
Sleep mode: Approx. 1.0 W
Typical Electricity Consumption (TEC): 0.23 kWh/week14
For detailed information relating to Lot26 regulation, please go to:
https://www.canon-europe.com/business/lot26/
Noise Levels
Sound Pressure15:
Active: Simplex 53 dB / Duplex 52 dB
Standby: Inaudible

Sound Power16:
Active: Simplex 67 dB or less (BW) / 66 dB or less (CL)
Duplex 66 dB or less
Standby: Inaudible

Consumables
Cartridges
Cartridge 075 Black (1,400 pages17)18
Cartridge 075H Black (3,500 pages19)20
Cartridge 075 Cyan (1,300 pages21)22
Cartridge 075H Cyan (2,500 pages 23)24
Cartridge 075 Magenta (1,300 pages25)26
Cartridge 075H Magenta (2,500 pages27)28
Cartridge 075 Yellow (1,300 pages29)30
Cartridge 075H Yellow (2,500 pages31)32
Accessories & Options
Items
TEL 6 Kit Long Cord (Telephone handset)
Barcode Printing Kit-E1E
Send PDF Security Feature Set-E1
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Accessory – Send PDF Security Feature Set-E1 is required
Scan by MF Scan Utility or Canon PRINT
Based on ITU-T Standard Chart No. 1
Based on ITU-T Standard Chart No. 1
Web distribution only. Linux support printing only.
Duty cycle is defined as the maximum number of printed pages for a single peak month. Any usage above the recommended duty cycle may decrease the life of the product
As per US ENERGY STAR® version3.2.
Declared noise emission in accordance with ISO 7779.
Declared noise emission in accordance with ISO 7779.
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
Based on ISO/IEC 19798
Printer ships with Black: 700 pages, C/M/Y: 500 pages starter cartridges
