Description
Specifications in detail
General Specifications
Machine Type
Mono Laser All-In-One
Available Functions
Print, Copy, Scan and Fax
Print Specifications
Print Speed
Single sided : Up to 40 ppm (A4)
Up to 65.4 ppm(A5-Landscape)
Double sided : Up to 33.6 ipm (A4)
Printing Method
Monochrome laser beam printing
Print Resolution
Up to 1200 x 1200 dpi
Warm-up Time
Approx. 14 seconds or less from power on
First-Print-Out Time
Approx: 5.0 seconds or less
Printer Languages
UFRII, PCL 5e1, PCL6, Adobe® PostScript2
Fonts
45 PCL fonts
136 PostScript fonts
Print Margins
5 mm-top, bottom, left and right
10 mm-top, bottom, left and right (Envelope)
Toner Saver Mode
Yes
Advanced Printing Features
Encrypted Secure Print
Secure Print
Print from USB memory key (JPEG/TIFF/PDF)
Print from Cloud (Dropbox, GoogleDrive, OneDrive) (PDF/JPEG)
Microsoft Universal Print
iOS: AirPrint, Canon PRINT app
Android; Mopria certified, Canon PRINT app, Canon Print Service Plug-in, IPP everywhere
Copy Specifications
Copy Speed
Single sided (A4): Up to 40 ppm
Double sided (A4): Up to 33.6 ipm
First-Copy-Out Time
Approx. 6.1 seconds or less
Copy Resolution
Up to 600 x 600 dpi
Copy Modes
Text, Text/Photo (Default),Text/Photo (High Quality), Photo
Double Sided Copying
2-sided to 2-sided (Automatic)
Multiple Copies
Up to 999 copies
Reduction / Enlargement
25-400% in 1% increments
Other Features
Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Two-sided Original, Sort, N on 1, Sharpness, Erase Frame, Copy ID Card, Copy Passport, Color Mode, Reserved copy
Scan Specifications
Standard Type
Colour
Scan Resolution
Optical: Up to 600 x 600 dpi
Enhanced: Up to 9600 x 9600 dpi
Scan Speed
Single sided mono: 50ipm (300x300dpi)
Single sided colour: 40ipm (300x300dpi)
Double sided mono: 100ipm (300x300dpi)
Double sided colour: 80ipm (300x300dpi)
Single sided mono: 40ipm (300x600dpi)
Single sided colour: 20ipm (300x600dpi)
Double sided mono: 80ipm (300x600dpi)
Double sided colour: 40ipm (300x600dpi)
Colour Scanning Depth
24 bit/24 bit (input/output)
Greyscales
256 levels
Compatibility
TWAIN , WIA, ICA
Maximum Scan Width
216mm
Scan to E-mail
TIFF/JPEG/PDF/Compact PDF/Searchable PDF / PDF/A-1b
Scan to Cloud
TIFF/JPEG/PDF/PNG3
iFAX
ITU-T.37
Fax Specifications
Modem Speed
33.6 Kbps (Up to 3 seconds/page3)
Receive Mode
Fax only, Fax/Tel Auto Switch, Answer Mode, Manual
Fax Resolution
Standard: 200 x 100 dpi
Fine: 200 x 200 dpi
Super fine: 200 x 400 dpi
Ultra fine: 400 x 400 dpi
Fax Memory
Up to 512 pages4
Speed Dials
Up to 281 dials
Group Dials/Destinations
Max. 299 dials / Max. 299 destinations
Sequential Broadcast
Max. 310 destinations
Memory Backup
Permanent fax memory backup (Backup with flash memory)
Double Sided Faxing
Yes (Transmit and Receive)
Other Features
Sender’s Name (TTI), Direct Send, TX Report, Sequential Broadcasting
Media Handling
Scanner Type
Platen, 2-sided ADF (single pass)
Paper Input (Standard)
250-sheet cassette
100-sheet multi-purpose tray
50-sheet ADF
Paper Input (Option)
550-sheet cassette
Maximum Paper Input Capacity
900 sheets
Paper Output
150-sheet
Media Types
Plain paper, Recycled paper, Heavy Paper, Thin paper, Label, Post card, Envelope
Media Sizes
Cassette (Standard and optional):
A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Custom sizes: Min. 105 x 148 mm Max. 216.0 x 355.6 mm.
Multi-purpose tray:
A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Indexcard, Envelope (COM10, Monarch, C5, DL), Custom sizes: Min 76.2 x 127 mm Max. 216.0 x 355.6 mm.
ADF:
A4, A5, A6, B5, Legal, Letter, Statement, Custom sizes: Min. 48 x 85.0 mm Max 216 x 355.6 mm
Media Weights
Cassette (standard and optional): 60 to 120 g/m2 Multi-purpose tray: 60 to 199 g/m2 ADF: 60 to 120 g/m2
Double Sided Printing
A4, Legal, Letter, OFFICIO, B-OFFICIO, M-OFFICIO, GLGL, Foolscap
Custom size – Min. 210 x 279.4 mm Max. 216.0 x 355.6 mm
60 to 120 g/m2
Interface & Software
Interface Type
USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T, Wireless 802.11b/g/n, Wireless Direct Connection
Operating System Compatibility
Windows® 11 / Windows® 10 / Server® 2025 / Server® 2022 / Server® 2019 / Server® 2016
Mac OS X version 10.15 & up
Linux5
Network Protocol
Print:
TCP/IP (LPD/Port9100/IPP/IPPS/WSD)
Scan:
Push Scan: File: FTP (TCP/IP), SMB3.1.1 (TCP/IP)
E-mail/I-Fax: SMTP (send), POP3 (receive)
Pull Scan: TCP/IP
Management:
SNMPv1, SNMPv3 (IPv4,IPv6)
Security:
TLS1.3, IPSec, IP address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
Security (wireless):
Infrastructure Mode:
WPA-PSK(AES), WPA2-PSK(AES), WPA3-SAE (AES), WPA-EAP(AES), WPA2-EAP(AES), WPA3-EAP(AES)
Access Point Mode:
WPA2-PSK(AES), WPA3-SAE (AES)
Software and Printer Management
MF Scan Utility,
Remote User Interface (RUI),
Department ID Management,
Toner Status Tool,
iW Enterprise Management Console: Server-based software for centralised management of a fleet of devices
Cooperating with External Security Audit System (Security Information and Event Management)
eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics
Application Library
General Features
Recommended Monthly Print Volume
750 – 4,000 pages per month
Duty Cycle
Max. 80,000 pages per month6
Processor Speed
1200MHz
Memory
1GB
Storage
4GB
Control Panel
12.7 cm LCD Colour Touch Screen
Dimensions with Trays (W x D x H)
420 mm x 460 mm x 375 mm
Installation Space (W x D x H)
689 mm x 1,081 mm x 824 mm
Weight
Approx. 16.3 Kg
Operating Environment
Temperature: 10 to 30ºC (50 to 86ºF)
Humidity: 20 to 80% RH (no condensation)
Power Source
220-240V(±10%) 50/60Hz (±2Hz)
Power Consumption
Maximum: Approx. 1,280 W
Active printing: Approx. 480W
Standby: Approx. 8 W
Sleep mode: Approx. 0.9 W
Typical Electricity Consumption (TEC): 0.32 kWh/week (230V) 7
For detailed information relating to Lot26 regulation, please go to: https://www.canon-europe.com/business/lot26/
Noise Levels
Sound Pressure8 :
Active: 53 dB
Standby: Inaudible9
Sound Power10:
Active: Duplex 68dB / Simplex 67dB
Standby: Inaudible11
A Canon PCL5e driver is not supplied, however PCL5e commands are supported on the device.
Scan by MF Scan Utility or Canon PRINT
Based on ITU-T Standard Chart No. 1
Based on ITU-T Standard Chart No. 1
Linux support both printing and scanning
Duty cycle is defined as the maximum number of printed pages for a single peak month. Any usage above the recommended duty cycle may decrease the life of the product
As per US ENERGY STAR® version 3.2
Declared noise emission in accordance with ISO 9296
Inaudible means that the emission sound pressure level for a bystander is lower than absolute standard for background noise in accordance with ISO 7779
Declared noise emission in accordance with ISO 9296
Inaudible means that the emission sound pressure level for a bystander is lower than absolute standard for background noise in accordance with ISO 7779
Based on ISO/IEC 19752
Printer ships with Cartridge 070 (3,000 pages)
Based on ISO/IEC 19752
Printer ships with Cartridge 070 (3,000 pages)
